Sub-Spindle Ejector Pin – Solid Design - ø1-1/2" body - M10 x 1.5 thread
$69.99
Big Ejector Pin – Solid Style
A simple, reliable solution for part ejection from the sub spindle—built for larger work across CNC lathes.
This solid ejector pin installs directly into the sub spindle to push finished parts clear of the collet during ejection cycles. The larger head provides rigidity, while the reduced shank keeps weight down.
The solid design (no thru-coolant) keeps things simple and dependable for shops that just need consistent, repeatable part ejection.
Built for durability and straightforward installation.
Specifications
- Overall length: 3"
- Head diameter: 1-1/2"
- Head thickness: 3/4"
- Body diameter: 3/4"
- Thread: M10 × 1.5
- Thread length: 20 mm
- Length (shoulder to ejector face): 2.2"
- Wrench flats: 1-3/8"
- Solid design (no thru-coolant)
- Lightweight aluminum
- Machined in-house by Cinci CNC
A straightforward shop tool for consistent, reliable sub spindle part ejection—especially when the job calls for something more robust.
